True’s air curtain merchandisers are designed with enduring quality that protects your long term investment. True’s commitment to using the highest quality materials and oversized refrigeration systems provides the user with colder product temperatures and lower utility costs in a convenient spot merchandiser for packaged food and beverage. Uniquely sized for placement in an variety of popular impulse merchandising locations. Oversized, factory balanced, refrigeration system holds 35°F to 40°F (1.6°C to 4.4°C). Exclusive reversing condenser fan motors. Fan motors reverse during defrost off cycles to help keep condenser coil free from dirt, dust and debris. Keeping coils clean optimizes the unit’s performance providing colder holding temperatures and increased energy efficiency. Regularly scheduled thorough cleaning of coils still recommended. Exterior – gleaming stainless steel for those who appreciate the value of stainless. Interior – matching aluminum interior liner with stainless steel floor. LED interior lighting, safety shielded. Air curtain top provides fast, easy access to product while maximizing attention to merchandising. Entire cabinet structure is foamed-in-place using a high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
| Specifications |
|
| Model |
THAC-60-S-HC-LD |
| Shelf Count |
3 |
| Weight (lbs) |
465 |
| Weight (KG) |
211 |
| Dimensions |
Imperial |
Metric |
| Width |
60–1/8 |
1528 |
| Depth |
30–1/8 |
766 |
| Height |
43–3/8 |
1102 |
| CORD LENGTH |
6.5 |
1.98 |
| Electrical |
|
| Amps |
15.0 |
| Voltage |
115/60/1 |
| NEMA Configuration |
5-20P |
Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8” (millimeters rounded up to next whole
number).
Design
▼
- Designed using the highest quality materials and components to provide the user with colder product temperatures and lower utility costs in an attractive merchandiser that brilliantly displays package food and beverage.
Refrigeration System
▼
- Factory engineered, self-contained, capillary tube system using environmentally friendly (CFC free) 134A refrigerant.
- Time initiated, time terminated off cycle defrost system
- Extra large evaporator coil balanced with higher horsepower compressor and large condenser; maintains cabinet temperatures of 35°F to 40°F (1.6°C to 4.4°C).
- Sealed, cast iron, self-lubricated evaporator fan motors and larger fan blades give True merchandisers a more efficient, low velocity, high volume airflow design, colder holding temperatures and faster recovery in high use situations.
- Condensing unit accessed from front of cabinet, slides out for easy maintenance.
- Exclusive reversing condenser fan motors. Fan motors reverse during defrost off cycles to help keep condenser coil free from dirt, dust and debris. Keeping coils clean optimizes the unit’s performance providing colder holding temperatures and increased energy efficiency. Regularly scheduled thorough cleaning of coils still recommended.
Cabinet Construction
▼
- Exterior - gleaming stainless steel for those who appreciate the value of stainless.
- Interior - matching aluminum interior liner with stainless steel floor.
- Cabinet fitted with leg levelers.
- Insulation - entire cabinet structure is foamed-in-place using a high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
- Interior - matching aluminum interior liner with stainless steel floor.
Shelving
▼
- Three (3) level tiered stainless steel floor.
Lighting
▼
- LED interior lighting, safety shielded.
Model Features
▼
- Listed under NSF/ANSI Standard 7 for the storage and/or display of packaged and bottled product.
Electrical
▼
- Unit completely pre-wired at factory and ready for final connection to a 115/60/1 phase - 20 amp dedicated outlet. Cord and plug set included.
- NEMA-5-20R
Optional Features/accessories Upcharge And Lead Times May Apply.
▼
- Black exterior.
- 2" (51 mm) diameter castors
- Bumper guards.
- Night cover.
