R290 Hydrocarbon refrigerant Temperatures of 33°F to 38°F (.5°C to 3.3°C) Exterior: Black powder coated cold rolled steel with stainless steel countertop Interior: Stainless steel Self-cleaning RCU technology White LED interior lighting NSF/ANSI standard 7 compliant for the storage and/or display of packaged or bottled product UL Rated for outdoor use Three (3) interior access ports Field reversible doors
- 3” (77mm) diameter stainless steel insulated column with single faucet
| Specifications |
|
| Model |
TDR60-RISZ1-L-S-SS-1 |
| Door Count |
2 |
| Capacity |
|
| 1/2 Barrels |
1 |
| 12 oz Cans |
38 6-pks |
| Dimensions |
Imperial |
Metric |
| Width |
60 |
1524 |
| Depth |
24–7/8 |
631 |
| Height |
34–3/4 |
881 |
| CORD LENGTH |
10 |
3.04 |
| Electrical |
|
| Amps |
3.2 |
| Voltage |
115/60/1 |
| NEMA Configuration |
5-15P |
Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8” (millimeters rounded up to next whole
number).
▼
Refrigeration System
▼
- Factory engineered, self-contained, capillary tube system
- Environmentally friendly R290 hydrocarbon refrigerant
- Forced air refrigeration system which maintains 33°F to 38°F (.5°C to 3.3°C) product temperatures
- True’s self-cleaning RCU technology eliminates the need to clean the condenser coil, reduces energy consumption and helps maintain the coldest temperatures and freshest product.
Cabinet Construction
▼
- Exterior: Black, powder coated cold-rolled steel with stainless steel countertop
- Interior: Stainless steel floor and sides with ABS plastic ceiling
- Insulation: Entire cabinet is foamed-in-place using a high density, polyurethane insulation that has zero ozone depletion and zero global warming potential
Doors
▼
- Door locks standard
- Field Reversible Doors standard (reverse hinge kit included)
- Door threshold with reinforced lip
Model Features
▼
- NSF/ANSI standard 7 compliant for the storage and/or display of packaged or bottled product
- UL approved for outdoor use
- Electronic temp control with exterior digital display
- Three (3) access ports standard (see drawing for locations)
- 3" (77mm) diameter insulated column with single faucet
Electrical
▼
- Unit completely pre-wired at factory and ready for final connection to a 115/60/1 phase, 15 amp dedicated outlet. Cord and plug set included.
- 115/60/1 NEMA-5-15R
Optional Features/accessories Upcharge And Lead Times May Apply.
▼
- TruLumina® 14-Color LED lighting
- Castors: 7/8" (23 mm) rollers, 2" (51mm), 3" (77mm), 4" (102mm), 5" (127mm) castors
- 6" (153mm) legs
- 6" (153mm) seismic legs
- Optional draft towers available (contact factory)
- Alternative temperature zones available (contact factory)
