Designed using the highest quality materials and components to provide the user with colder product temperatures, lower utility costs and exceptional food safety. Factory engineered, self-contained, capillary tube system using environmentally friendly R290 hydrocarbon refrigerant that has zero (0) ozone depletion potential (ODP), & three (3) global warming potential (GWP). High capacity, factory balanced refrigeration system that maintains -10Ā°F (-23.3Ā°C) temperatures. Ideal for both frozen foods and ice cream. Stainless steel exterior and interior. Triple pane thermal glass assembly with extruded aluminum frame. Equipped with one (1) factory installed interior kit option. Four (4) different interior kits available (see Kit Options). Positive seal self-closing door with 120Ā° stay open feature. Lifetime guaranteed door hinges. Lifetime guaranteed heavy duty all metal working door handle. Entire cabinet structure is foamed-in-place using a high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
| Specifications |
|
| Model |
STR1F-1G-HC |
| Door Count |
1 |
| Shelf Count |
3 |
| Weight (lbs) |
520 |
| Weight (KG) |
236 |
| Dimensions |
Imperial |
Metric |
| Width |
27ā1/2 |
699 |
| Depth |
33ā3/4 |
858 |
| Height |
77ā3/4 |
1975 |
| CORD LENGTH |
9 |
2.74 |
| Electrical |
|
| Amps |
8.9 |
| Voltage |
115/60/1 |
| NEMA Configuration |
5-15P |
Specifications subject to change without notice.
Chart dimensions rounded up to the nearest 1/8ā (millimeters rounded up to next whole
number).
Design
ā¼
- Trueās glass door reach-inās are designed with enduring quality that protects your long term investment.
- Designed using the highest quality materials and components to provide the user with colder product temperatures, lower utility costs and exceptional food safety.
Refrigeration System
ā¼
- Factory engineered, self-contained, expansion valve (TXV) system using environmentally friendly R290 hydrocarbon refrigerant that has zero (0) ozone depletion potential (ODP), & 0.02 global warming potential (GWP).
- High capacity, factory balanced refrigeration system that maintains -10Ā°F (-23.3Ā°C) temperatures. Ideal for both frozen foods and ice cream.
- State of the art, electronically commutated evaporator and condenser fan motors. ECM motors operate at higher peak efficiencies and move a more consistent volume of air which produces less heat, reduces energy consumption and provides greater motor reliability.
- Top mounted refrigeration system with evaporator positioned out of food zone to maximize capacity.
Cabinet Construction
ā¼
- Insulation - entire cabinet structure and solid door are foamed-in-place using a high density, polyurethane insulation that has zero ozone depletion potential (ODP) and zero global warming potential (GWP).
Door
ā¼
- Triple pane thermal glass assembly with extruded aluminum frame.
- Lifetime guaranteed bolt style door lock standard.
- Lifetime guaranteed heavy duty all metal working door handle.
- Positive seal self-closing door with 120Ā°Ā stay open feature. Lifetime guaranteed external cam lift door hinges, four (4) per door section.
- Magnetic door gaskets of one piece construction, removable without tools for ease of cleaning.
Shelving
ā¼
- One (1) factory installed interior kit option. Four (4) different interior kits available (see Kit Options). Pilasters and tray slides are factory installed at no charge.
Lighting
ā¼
- LED interior lighting, safety shielded.
Model Features
ā¼
- Exterior digital temperature display, available with either Ā°F or Ā°C .
- Evaporator epoxy coated to eliminate the potential of corrosion
- Curb mounting ready.
- NSF/ANSI Standard 7 compliant for open food product.
Electrical
ā¼
- Unit completely pre-wired at factory and ready for final connection to a 115/60/1 phase, 15 amp dedicated outlet. Cord and plug set included.
- 115/60/1 NEMA-5-15R
Optional Features/accessories Upcharge And Lead Times May Apply.
ā¼
- 6" (153 mm) standard legs.
- 6" (153 mm) seismic/flanged legs.
- 6" (153 mm) stainless steel legs.
- Hasp lock.
- Additional shelves.
- Stainless back. (STR, STA, STG)
- Security package.
- 3ā1/4" (83mm) castors
SHELVING KIT OPTIONS
